We are a manufactuer and have our own factory, we provide many kinds of industrial panel pcs , such as panel mount industrial panel pc, rackmount industrial panel pc, high performance industrial panel pcs, from 8.4" to 19", and also provide industrial lcd monitor, fanless embedded computer,mini-itx motherboard ect

Product Feature
17" LCD Industrial Rack mount computer,all in one pc,Panel PC RGPC-D5217

Feature:
17" XGA TFT LCD Panel support 1280 × 1024 pixels
. Compact 19"Rack mount with 8U height
. Intel Atom D525 ( Dual-core 1.8GHz processor ) CPU with 667 MHz FSB
. Front hardness glass protect screen ( touch option )
. 4 * COM, 1* LPT, 2 * PS/2, 1 * VGA, 4 * USB, 2* LAN, 1* AUDIO, 1* MIC
. 1 * PCI Slot, 1 * Mini PCIe slot,
. Wireless LAN with antenna (option)

Product Specification/Models
Specification:
TFT Characteristics
Display Type: 17" SXGA TFT LCD
Pixel Number: 1280 x 1024
Pixel Pitch(RGB): 0.264*0.264
Contrast Ratio : 1000: 1
Light Intensity : 300 cd/m2
Viewable Angles : 178°(H) , 178°(V)
Max Colors : 16.7MB
Response Time: 5 ms
MTBF: 50,000hrs.

System Characteristics
Processor: Intel Atom D525 Dual-core 1.8GHz processor with 667 MHz FSB Chipset Intel NM10
Memory: 1 x SODIMM DDR3 800/1066/1333 SDRAM up to 4GB. Graphic Intel GMA3150chipset
Storage : 1 x 2.5" SATA HDD / SSD/ 1 compact flash card slot Audio Realtek ALC662,5.1 Channel surround Audio
USB Port: 4 x USB2.0
Ethernet : 10/100/1000M Ethernet
VGA Port: 1 x VGA Connector
Speakers : Optional
Serial Port : 4 x COM ( 3 x RS232,1 x RS232/422/485)
Expansive Slot : 1 x PCI, 1 x Mini PCIe
KB & Mouse: 1 x PS2 port
Watchdog Timer: 255Levels,1-255sec.

Available Options
Touch Screen: 5 wire Resistive Wireless
LAN Meet IEEE802.11b/gstandard.
DC Power Input: DC 8 -30V
Speakers: 2

I/O Connector
PS/2: 1 x PS2 for KB/ Mouse
Lan 2 x 100/1000M Lan port(RJ-45) )
VGA: 1 x VGA
USB: 4 x USB2.0
RS-232: 4 x COM( 3XRS232,1X RS422/485)
Power Switch: 1 x Power Switch,1xReset switch
DC Input: 1 x Lockable
DC Input connector
Audio 1 x Lin-out / Mic-in

Mechanical and Environmental
Construction Heavy duty steel chassis enclosure
Storage humidity 10% to 90% non-condensing
Operating temperature 32°F~125°F(0°C to 50°C)
Anti-Vibration 17 to 500Hz 1G PTP
Storage temperature: -4°F~140°F(-20°C to 60°C)
Dimensions(WxHxD :322 x 247.5 x 71mm
Anti-Shock 1g/peak(11ms)
Weight Net:10.5KG,Volume Gross:13.5KG

Power Specification
Output DC12V@ 8A / 96W, external AC Power Adapter Input 100~240VAC,50/60Hz
Certification CE/FCC/ROHS


Ordering Information
RGPC-D5217T: 17" XGA Rack Mount Industrial Panel PC,support Intel Atom D525 Dual-core 1.8GHz Processor, with 17" 5 wire resistive touchscreen, 320G HDD,2G DDR3 RAM, DC12V power supply

Optional:
Storage: 16G SSD/32G SSD/8G CF card
Wireless LAN: Wifi
Power supply: DC8-30V
Speakers: 2

Application
industrial

Other Information
