Cheap Industrial LCD Monitor  VGA input IPM-22W


1. 22"WSXGA TFT LCD Panel support 1680x1050pixels
2. 6mm Aluminum front bezel with strengthen glass
3. Rugged construction and modularized design
4. Input signal : VGA +DVI+ Audio
5. 250 cd/m2 brightness
6. Build in 2x2 Watts stereo speaker
7. OSD control keys to optimize the display
8. AC 100-240V wide range external ac adapter
9. Panel(Flush) mount with bracket
10. NEMA4 / IP 65 compliant front panel

Specification:

TFT Characteristics
Display Type 22" SVGA TFT LCD
Resolution 1680 x 1050

Pixel Pitch(RGB) 0.282x 0.282 mm
Contrast Ratio 1000 : 1

Light Intensity 250 cd/m2
Viewable Angles 170H , 160V

Max Colors 16.7M
Response Time 5 ms
MTBF 50,000hrs.


Available Options

Touch Screen
Resistive type with USB and RS232 controller

DC power input
Wide Range 8-30V DC input

AV input
Composite Video/Audio, S-video input


Input
100~240VAC,50/60Hz

Output
DC12V 5A/60W,external AC adapter

Mechanical and Environmental

Construction
Heavy duty steel and aluminum front panel

Operating temperature
32F~113F 0C to 50C
Storage temperature
-4F~140F -20C to 60C

Storage humidity
10% to 90%non-condensing
Vibration
17 to 500HZ 1G PTP

Anti-Shock
1G /peak 11m sec

Input Signals

RGB Signal
D-SUB 15p Connector Female

DC input
DC jack (2.1mm)

Video Input (option)
RCA Connector

S-Video Signal (option
S-Video (Svhs) Plug

DVI-D Signal
DVI-D input 24pin connector (Female)

Touch screen RS232 (option)
D-SUB 9p Connector (Female)

Touch screen USB (option

USB-A Type connector (Female)


Certificate CE/FCC/ROSH

VGA+DVI input

IPM-22W
22" Industrial Flat Panel Monitor with VGA+ DV I+ Audio input

IPM-22WT/C
22" Industrial Flat Panel Monito
